Product Overview
- No Heat, No Burrs & Virtually No Sparks.
- 2 In. x 4 In. Cross Cut Capacity.
- Pressed Steel Base | Quick, Accurate Angle Adjustments.
- Powerful 10A High Torque Motor.
The EVOSAW185 easily cuts mild steel without heat or burrs and virtually no sparks. The quick-release adjustable vise allows for fast and accurate angle cuts from 0-45˚. Ideal for cutting steel plate, square tube, angle iron, pipe, rebar, copper pipe, conduit, and steel studs.No Heat, No Burrs & Virtually No Sparks.No Coolant Required.Pressed Steel Base.10A Powerful High Torque Motor.2 In. x 4 In. Cross Cut Capacity.2 In. x 2 In. Square Tube Capacity.2 In. Ø Round Tube Capacity.3 Years Limited Warranty.
Cutting Capacities
| Mild Steel Plate (Max Thickness): | 1/4 In. |
| Mild Steel Box Section (Max Wall Thickness): | 1/8 In. |
| Square Tube at 90° (Mild Steel): | 2 In. |
| Square Tube at 45° (Mild Steel): | 2 In. |
| Rectangle Tube at 90° (Mild Steel): | 2 In. x 4 In. |
| Rectangle Tube at 45° (Mild Steel): | 2 In. x 2 In. |
| Round Tube at 90° (Mild Steel): | ø 2 In. |
| Round Tube at 45° (Mild Steel): |
ø 2 In. |
Specifications
Machine
| Motor (120V 60Hz): | 10 A |
| Speed No Load: | 4200 rpm |
| Max. Bevel (Left): | 45° |
| Cable Length: | 6-9/16 ft |
Blade
| Blade Diameter | 7-1/4 In. |
| No. of Teeth: | 40 |
| Arbor | 20mm |
| Kerf | .078 In. |
Dimensions
| Motor (120V 60Hz): | 10 A |
| Speed No Load: | 4200 rpm |
| Max. Bevel (Left): | 45° |
| Cable Length: | 6-9/16 ft |
Items Included
| 40T Mild Steel TCT Blade | |
| Hex Key 6mm (Vise Adjustment) | |
| Hex Key 5mm (Blade Change) | |
| Hex Key 3mm (Upper Blade Guard) | |
| Dust Extraction Port 36mm | |
| Speed Handle | |
| Spare Motor Brushes (1 set) |
